Description
Item NO. | Watts | Lumen(CRI>90) | Size |
ILED-TL-D2 | 10W | 1000LM | D62xL170xH140mm |
ILED-TL-D3 | 20W | 2000LM | D72xL185xH170mm |
ILED-TL-D4 | 30W | 3000LM | D80xL185xH175mm |
ILED-TL-D6 | 40W | 4000LM | D94xL190xH180mm |
Input |
220-240VAC(Tridonic Driver) or 110-277VAC |
LED Source |
Citizen COB LM80 |
Watts |
15W/30W/40W |
Lumen Effective |
100-110LM/W |
Lumen Output |
1500LM / 3000LM / 4000LM
|
Adapter |
3 Phase 4 Wires for European 1 Phase 3 Wires for US
|
Materials |
Aluminum+PC |
PF |
>0.9 |
CCT |
2800-6500K |
CRI |
>92 or >97 |
Electrical Classification |
Class I |
IP Class |
IP42 |
Beam Angel |
12°,24°,36°or 60° |
Body Color |
White Black |
Warranty |
3-5 years |
Certifications |
SAA,CE,RoHS |
